Bearing model list
| Zahnteilung / Tooth pitch 8M Tab. 8 | |||||||||
| Zahnezahl | Wirk-0 | AuBen-0 | |||||||
| Number of | Pitch | Outside | |||||||
| teeth | diameter | diameter | |||||||
| mm | mm | ||||||||
| z | dw | da | |||||||
| CTD C8M | CTD C8M-22 | 22 | 56.02 | 54.42 | CTD C14M | CTD C14M-28 | 28 | 124.78 | 121.99 |
| CTD C8M | CTD C8M-23 | 23 | 58.57 | 56.97 | CTD C14M | CTD C14M-29 | 29 | 129.23 | 126.44 |
| CTD C8M | CTD C8M-24 | 24 | 61.12 | 59.52 | CTD C14M | CTD C14M-30 | 30 | 133.69 | 130.9 |
| CTD C8M | CTD C8M-25 | 25 | 63.66 | 62.06 | CTD C14M | CTD C14M-31 | 31 | 138.15 | 135.36 |
| CTD C8M | CTD C8M-26 | 26 | 66.21 | 64.61 | CTD C14M | CTD C14M-32 | 32 | 142.6 | 139.81 |
| CTD C8M | CTD C8M-27 | 27 | 68.75 | 67.15 | CTD C14M | CTD C14M-33 | 33 | 147.06 | 144.27 |
| CTD C8M | CTD C8M-28 | 28 | 71.3 | 69.7 | CTD C14M | CTD C14M-34 | 34 | 151.52 | 148.73 |
| CTD C8M | CTD C8M-29 | 29 | 73.85 | 72.25 | CTD C14M | CTD C14M-35 | 35 | 155.97 | 153.18 |
| CTD C8M | CTD C8M-30 | 30 | 76.39 | 74.79 | CTD C14M | CTD C14M-36 | 36 | 160.43 | 157.64 |
| CTD C8M | CTD C8M-31 | 31 | 78.94 | 77.34 | CTD C14M | CTD C14M-37 | 37 | 164.88 | 162.09 |
| CTD C8M | CTD C8M-32 | 32 | 81.49 | 81.49 | CTD C14M | CTD C14M-38 | 38 | 169.34 | 166.55 |
| CTD C8M | CTD C8M-33 | 33 | 84.03 | 82.43 | CTD C14M | CTD C14M-39 | 39 | 173.8 | 171.01 |
| CTD C8M | CTD C8M-34 | 34 | 86.58 | 84.98 | CTD C14M | CTD C14M-40 | 40 | 178.25 | 175.46 |
| CTD C8M | CTD C8M-35 | 35 | 89.13 | 87.53 | CTD C14M | CTD C14M-41 | 41 | 182.71 | 179.92 |
| CTD C8M | CTD C8M-36 | 36 | 91.67 | 90.07 | CTD C14M | CTD C14M-42 | 42 | 187.17 | 184.38 |
| CTD C8M | CTD C8M-37 | 37 | 94.22 | 92.62 | CTD C14M | CTD C14M-43 | 43 | 191.62 | 188.83 |
| CTD C8M | CTD C8M-38 | 38 | 96.77 | 95.17 | CTD C14M | CTD C14M-44 | 44 | 196.08 | 193.29 |
| CTD C8M | CTD C8M-39 | 39 | 99.31 | 97.71 | CTD C14M | CTD C14M-45 | 45 | 200.54 | 197.75 |
| CTD C8M | CTD C8M-40 | 40 | 101.86 | 100.26 | CTD C14M | CTD C14M-46 | 46 | 204.99 | 202.2 |
| CTD C8M | CTD C8M-41 | 41 | 104.41 | 102.81 | CTD C14M | CTD C14M-47 | 47 | 209.45 | 206.66 |
| CTD C8M | CTD C8M-42 | 42 | 106.95 | 105.35 | CTD C14M | CTD C14M-48 | 48 | 213.9 | 211.11 |
| CTD C8M | CTD C8M-43 | 43 | 109.5 | 107.9 | CTD C14M | CTD C14M-49 | 49 | 218.36 | 215.57 |
| CTD C8M | CTD C8M-44 | 44 | 112.05 | 110.45 | CTD C14M | CTD C14M-50 | 50 | 222.82 | 220.03 |
| CTD C8M | CTD C8M-45 | 45 | 114.59 | 112.99 | CTD C14M | CTD C14M-51 | 51 | 227.27 | 224.48 |
| CTD C8M | CTD C8M-46 | 46 | 117.14 | 115.54 | CTD C14M | CTD C14M-52 | 52 | 231.73 | 228.94 |
| CTD C8M | CTD C8M-47 | 47 | 119.68 | 118.08 | CTD C14M | CTD C14M-53 | 53 | 236.19 | 233.4 |
| CTD C8M | CTD C8M-48 | 48 | 122.23 | 120.63 | CTD C14M | CTD C14M-54 | 54 | 240.64 | 237.85 |
| CTD C8M | CTD C8M-49 | 49 | 124.78 | 123.18 | CTD C14M | CTD C14M-55 | 55 | 245.1 | 242.31 |
| CTD C8M | CTD C8M-50 | 50 | 127.32 | 125.72 | CTD C14M | CTD C14M-56 | 56 | 249.55 | 246.76 |
| CTD C8M | CTD C8M-51 | 51 | 129.87 | 128.27 | CTD C14M | CTD C14M-57 | 57 | 254.01 | 251.22 |
| CTD C8M | CTD C8M-52 | 52 | 132.42 | 130.82 | CTD C14M | CTD C14M-58 | 58 | 258.47 | 255.68 |
| CTD C8M | CTD C8M-53 | 53 | 134.96 | 133.36 | CTD C14M | CTD C14M-59 | 59 | 262.92 | 260.13 |
| CTD C8M | CTD C8M-54 | 54 | 137.51 | 135.91 | CTD C14M | CTD C14M-60 | 60 | 267.38 | 264.59 |
| CTD C8M | CTD C8M-55 | 55 | 140.06 | 138.46 | CTD C14M | CTD C14M-61 | 61 | 271.84 | 269.05 |
| CTD C8M | CTD C8M-56 | 56 | 142.6 | 141 | CTD C14M | CTD C14M-62 | 62 | 276.29 | 273.5 |
| CTD C8M | CTD C8M-57 | 57 | 145.15 | 143.55 | CTD C14M | CTD C14M-63 | 63 | 280.75 | 277.96 |
| CTD C8M | CTD C8M-58 | 58 | 147.7 | 146.1 | CTD C14M | CTD C14M-64 | 64 | 285.21 | 282.42 |
| CTD C8M | CTD C8M-59 | 59 | 150.24 | 148.64 | CTD C14M | CTD C14M-65 | 65 | 289.66 | 286.87 |
| CTD C8M | CTD C8M-60 | 60 | 152.79 | 151.19 | CTD C14M | CTD C14M-66 | 66 | 294.12 | 291.33 |
| CTD C8M | CTD C8M-61 | 61 | 155.34 | 153.74 | CTD C14M | CTD C14M-67 | 67 | 298.57 | 295.78 |
| CTD C8M | CTD C8M-62 | 62 | 157.88 | 156.28 | CTD C14M | CTD C14M-68 | 68 | 303.03 | 300.24 |
| CTD C8M | CTD C8M-63 | 63 | 160.43 | 158.83 | CTD C14M | CTD C14M-69 | 69 | 307.49 | 304.7 |
| CTD C8M | CTD C8M-64 | 64 | 162.97 | 161.37 | CTD C14M | CTD C14M-70 | 70 | 311.94 | 309.15 |
| CTD C8M | CTD C8M-65 | 65 | 165.52 | 163.92 | CTD C14M | CTD C14M-71 | 71 | 316.4 | 313.61 |
| CTD C8M | CTD C8M-66 | 66 | 168.07 | 166.47 | CTD C14M | CTD C14M-72 | 72 | 320.86 | 318.07 |
| CTD C8M | CTD C8M-67 | 67 | 170.61 | 169.01 | CTD C14M | CTD C14M-73 | 73 | 325.31 | 322.52 |
| CTD C8M | CTD C8M-68 | 68 | 173.16 | 171.56 | CTD C14M | CTD C14M-74 | 74 | 329.77 | 326.98 |
| CTD C8M | CTD C8M-69 | 69 | 175.71 | 174.11 | CTD C14M | CTD C14M-75 | 75 | 334.23 | 331.44 |
| CTD C8M | CTD C8M-70 | 70 | 178.25 | 176.65 | CTD C14M | CTD C14M-76 | 76 | 338.68 | 335.89 |
| CTD C8M | CTD C8M-71 | 71 | 180.8 | 179.2 | CTD C14M | CTD C14M-77 | 77 | 343.14 | 340.35 |
| CTD C8M | CTD C8M-72 | 72 | 183.35 | 181.75 | CTD C14M | CTD C14M-78 | 78 | 347.59 | 344.8 |
| CTD C8M | CTD C8M-73 | 73 | 185.89 | 184.29 | CTD C14M | CTD C14M-79 | 79 | 352.05 | 349.26 |
| CTD C8M | CTD C8M-74 | 74 | 188.44 | 186.84 | CTD C14M | CTD C14M-80 | 80 | 356.51 | 353.72 |
| CTD C8M | CTD C8M-75 | 75 | 190.99 | 189.39 | CTD C14M | CTD C14M-81 | 81 | 360.96 | 358.17 |
| CTD C8M | CTD C8M-76 | 76 | 193.53 | 191.93 | CTD C14M | CTD C14M-82 | 82 | 365.42 | 362.63 |
| CTD C8M | CTD C8M-77 | 77 | 196.08 | 194.48 | CTD C14M | CTD C14M-83 | 83 | 369.88 | 367.09 |
| CTD C8M | CTD C8M-78 | 78 | 198.63 | 197.03 | CTD C14M | CTD C14M-84 | 84 | 374.33 | 371.54 |
| CTD C8M | CTD C8M-79 | 79 | 201.17 | 199.57 | CTD C14M | CTD C14M-85 | 85 | 378.79 | 376 |
| CTD C8M | CTD C8M-80 | 80 | 203.72 | 202.12 | CTD C14M | CTD C14M-86 | 86 | 383.25 | 380.46 |
| CTD C8M | CTD C8M-81 | 81 | 206.26 | 204.66 | CTD C14M | CTD C14M-87 | 87 | 387.7 | 384.91 |
| CTD C8M | CTD C8M-82 | 82 | 208.81 | 207.21 | CTD C14M | CTD C14M-88 | 88 | 392.16 | 389.37 |
| CTD C8M | CTD C8M-83 | 83 | 211.36 | 209.76 | CTD C14M | CTD C14M-89 | 89 | 396.61 | 393.82 |
| CTD C8M | CTD C8M-84 | 84 | 213.9 | 212.3 | CTD C14M | CTD C14M-90 | 90 | 401.07 | 398.28 |
| CTD C8M | CTD C8M-85 | 85 | 216.45 | 214.85 | CTD C14M | CTD C14M-91 | 91 | 405.53 | 402.74 |
| CTD C8M | CTD C8M-86 | 86 | 219 | 217.4 | CTD C14M | CTD C14M-92 | 92 | 409.98 | 407.19 |
| CTD C8M | CTD C8M-87 | 87 | 221.54 | 219.94 | CTD C14M | CTD C14M-93 | 93 | 414.44 | 411.65 |
| CTD C8M | CTD C8M-88 | 88 | 224.09 | 222.49 | CTD C14M | CTD C14M-94 | 94 | 418.9 | 416.11 |
| CTD C8M | CTD C8M-89 | 89 | 226.64 | 225.04 | CTD C14M | CTD C14M-95 | 95 | 423.35 | 420.56 |
| CTD C8M | CTD C8M-90 | 90 | 229.18 | 227.58 | CTD C14M | CTD C14M-96 | 96 | 427.81 | 425.02 |
| CTD C8M | CTD C8M-91 | 91 | 231.73 | 230.13 | CTD C14M | CTD C14M-97 | 97 | 432.26 | 429.47 |
| CTD C8M | CTD C8M-92 | 92 | 234.28 | 232.68 | CTD C14M | CTD C14M-98 | 98 | 436.72 | 433.93 |
| CTD C8M | CTD C8M-93 | 93 | 236.82 | 235.22 | CTD C14M | CTD C14M-99 | 99 | 441.18 | 438.39 |
| CTD C8M | CTD C8M-94 | 94 | 239.37 | 237.77 | CTD C14M | CTD C14M-100 | 100 | 445.63 | 442.84 |
| CTD C8M | CTD C8M-95 | 95 | 241.92 | 240.32 | CTD C14M | CTD C14M-101 | 101 | 450.09 | 447.3 |
| CTD C8M | CTD C8M-96 | 96 | 244.46 | 242.86 | CTD C14M | CTD C14M-102 | 102 | 454.55 | 451.76 |
| CTD C8M | CTD C8M-97 | 97 | 247.01 | 245.41 | CTD C14M | CTD C14M-103 | 103 | 459 | 456.21 |
| CTD C8M | CTD C8M-98 | 98 | 249.55 | 247.95 | CTD C14M | CTD C14M-104 | 104 | 463.46 | 460.67 |
| CTD C8M | CTD C8M-99 | 99 | 252.1 | 250.5 | CTD C14M | CTD C14M-105 | 105 | 467.92 | 465.13 |
| CTD C8M | CTD C8M-100 | 100 | 254.65 | 253.05 | CTD C14M | CTD C14M-106 | 106 | 472.37 | 469.58 |
| CTD C8M | CTD C8M-101 | 101 | 257.19 | 255.59 | CTD C14M | CTD C14M-107 | 107 | 476.83 | 474.04 |
| CTD C8M | CTD C8M-102 | 102 | 259.74 | 258.14 | CTD C14M | CTD C14M-108 | 108 | 481.28 | 478.49 |
| CTD C8M | CTD C8M-103 | 103 | 262.29 | 260.69 | CTD C14M | CTD C14M-109 | 109 | 485.74 | 482.95 |
| CTD C8M | CTD C8M-104 | 104 | 264.83 | 263.23 | CTD C14M | CTD C14M-110 | 110 | 490.2 | 487.41 |
| CTD C8M | CTD C8M-105 | 105 | 267.38 | 265.78 | CTD C14M | CTD C14M-111 | 111 | 494.65 | 491.86 |
| CTD C8M | CTD C8M-106 | 106 | 269.93 | 268.33 | CTD C14M | CTD C14M-112 | 112 | 499.11 | 496.32 |
| CTD C8M | CTD C8M-107 | 107 | 272.47 | 270.87 | CTD C14M | CTD C14M-113 | 113 | 503.57 | 500.78 |
| CTD C8M | CTD C8M-108 | 108 | 275.02 | 273.42 | CTD C14M | CTD C14M-114 | 114 | 508.02 | 505.23 |
| CTD C8M | CTD C8M-109 | 109 | 277.57 | 275.97 | CTD C14M | CTD C14M-115 | 115 | 512.48 | 509.69 |
| CTD C8M | CTD C8M-110 | 110 | 280.11 | 278.51 | CTD C14M | CTD C14M-116 | 116 | 516.94 | 514.15 |
| CTD C8M | CTD C8M-111 | 111 | 282.66 | 281.06 | CTD C14M | CTD C14M-117 | 117 | 521.39 | 518.6 |
| CTD C8M | CTD C8M-112 | 112 | 285.21 | 283.61 | CTD C14M | CTD C14M-118 | 118 | 525.85 | 523.06 |
| CTD C8M | CTD C8M-113 | 113 | 287.75 | 286.15 | CTD C14M | CTD C14M-119 | 119 | 530.3 | 527.51 |
| CTD C8M | CTD C8M-114 | 114 | 290.3 | 288.7 | CTD C14M | CTD C14M-120 | 120 | 534.76 | 531.97 |
| CTD C8M | CTD C8M-115 | 115 | 292.85 | 291.25 | CTD C14M | CTD C14M-121 | 121 | 539.22 | 536.43 |
| CTD C8M | CTD C8M-116 | 116 | 295.39 | 293.79 | CTD C14M | CTD C14M-122 | 122 | 543.67 | 540.88 |
| CTD C8M | CTD C8M-117 | 117 | 297.94 | 296.34 | CTD C14M | CTD C14M-123 | 123 | 548.13 | 545.34 |
| CTD C8M | CTD C8M-118 | 118 | 300.48 | 298.88 | CTD C14M | CTD C14M-124 | 124 | 552.59 | 549.8 |
| CTD C8M | CTD C8M-119 | 119 | 303.03 | 301.43 | CTD C14M | CTD C14M-125 | 125 | 557.04 | 554.25 |
| CTD C8M | CTD C8M-120 | 120 | 305.58 | 303.98 | CTD C14M | CTD C14M-126 | 126 | 561.5 | 558.71 |
| CTD C8M | CTD C8M-121 | 121 | 308.12 | 306.52 | CTD C14M | CTD C14M-127 | 127 | 565.95 | 563.16 |
| CTD C8M | CTD C8M-122 | 122 | 310.67 | 309.07 | CTD C14M | CTD C14M-128 | 128 | 570.41 | 567.62 |
| CTD C8M | CTD C8M-123 | 123 | 313.22 | 311.62 | CTD C14M | CTD C14M-129 | 129 | 574.87 | 572.08 |
| CTD C8M | CTD C8M-124 | 124 | 315.76 | 314.16 | CTD C14M | CTD C14M-130 | 130 | 579.32 | 576.53 |
| CTD C8M | CTD C8M-125 | 125 | 318.31 | 316.71 | CTD C14M | CTD C14M-131 | 131 | 583.78 | 580.99 |
| CTD C8M | CTD C8M-126 | 126 | 320.86 | 319.26 | CTD C14M | CTD C14M-132 | 132 | 588.24 | 585.45 |
| CTD C8M | CTD C8M-127 | 127 | 323.4 | 321.8 | CTD C14M | CTD C14M-133 | 133 | 592.69 | 589.9 |
| CTD C8M | CTD C8M-128 | 128 | 325.95 | 324.35 | CTD C14M | CTD C14M-134 | 134 | 597.15 | 594.36 |
| CTD C8M | CTD C8M-129 | 129 | 328.5 | 326.9 | CTD C14M | CTD C14M-135 | 135 | 601.61 | 598.82 |
| CTD C8M | CTD C8M-130 | 130 | 331.04 | 329.44 | CTD C14M | CTD C14M-136 | 136 | 606.06 | 603.27 |
| CTD C8M | CTD C8M-131 | 131 | 333.59 | 331.99 | CTD C14M | CTD C14M-137 | 137 | 610.52 | 607.73 |
| CTD C8M | CTD C8M-132 | 132 | 336.14 | 334.54 | CTD C14M | CTD C14M-138 | 138 | 614.97 | 612.18 |
| CTD C8M | CTD C8M-133 | 133 | 338.68 | 337.08 | CTD C14M | CTD C14M-139 | 139 | 619.43 | 616.64 |
| CTD C8M | CTD C8M-134 | 134 | 341.23 | 339.63 | CTD C14M | CTD C14M-140 | 140 | 623.89 | 621.1 |
| CTD C8M | CTD C8M-135 | 135 | 343.77 | 342.17 | CTD C14M | CTD C14M-141 | 141 | 628.34 | 625.55 |
| CTD C8M | CTD C8M-136 | 136 | 346.32 | 344.72 | CTD C14M | CTD C14M-142 | 142 | 632.8 | 630.01 |
| CTD C8M | CTD C8M-137 | 137 | 348.87 | 347.27 | CTD C14M | CTD C14M-143 | 143 | 637.26 | 634.47 |
| CTD C8M | CTD C8M-138 | 138 | 351.41 | 349.81 | CTD C14M | CTD C14M-144 | 144 | 641.71 | 638.92 |
| CTD C8M | CTD C8M-139 | 139 | 353.96 | 352.36 | CTD C14M | CTD C14M-145 | 145 | 646.17 | 643.38 |
| CTD C8M | CTD C8M-140 | 140 | 356.51 | 354.91 | CTD C14M | CTD C14M-146 | 146 | 650.63 | 647.84 |
| CTD C8M | CTD C8M-141 | 141 | 359.05 | 357.45 | CTD C14M | CTD C14M-147 | 147 | 655.08 | 652.29 |
| CTD C8M | CTD C8M-142 | 142 | 361.6 | 360 | CTD C14M | CTD C14M-148 | 148 | 659.54 | 656.75 |
| CTD C8M | CTD C8M-143 | 143 | 364.15 | 362.55 | CTD C14M | CTD C14M-149 | 149 | 663.99 | 661.2 |
| CTD C8M | CTD C8M-144 | 144 | 366.69 | 365.09 | CTD C14M | CTD C14M-150 | 150 | 668.45 | 665.66 |
| CTD C8M | CTD C8M-145 | 145 | 369.24 | 367.64 | CTD C14M | CTD C14M-151 | 151 | 672.91 | 670.12 |
| CTD C8M | CTD C8M-146 | 146 | 371.79 | 370.19 | CTD C14M | CTD C14M-152 | 152 | 677.36 | 674.57 |
| CTD C8M | CTD C8M-147 | 147 | 374.33 | 372.73 | CTD C14M | CTD C14M-153 | 153 | 681.82 | 679.03 |
| CTD C8M | CTD C8M-148 | 148 | 376.88 | 375.28 | CTD C14M | CTD C14M-154 | 154 | 686.28 | 683.49 |
| CTD C8M | CTD C8M-149 | 149 | 379.43 | 377.83 | CTD C14M | CTD C14M-155 | 155 | 690.73 | 687.94 |
| CTD C8M | CTD C8M-150 | 150 | 381.97 | 380.37 | CTD C14M | CTD C14M-156 | 156 | 695.19 | 692.4 |
| CTD C8M | CTD C8M-151 | 151 | 384.52 | 382.92 | CTD C14M | CTD C14M-157 | 157 | 699.65 | 696.86 |
| CTD C8M | CTD C8M-152 | 152 | 387.06 | 385.46 | CTD C14M | CTD C14M-158 | 158 | 704.1 | 701.31 |
| CTD C8M | CTD C8M-153 | 153 | 389.61 | 388.01 | CTD C14M | CTD C14M-159 | 159 | 708.56 | 705.77 |
| CTD C8M | CTD C8M-154 | 154 | 392.16 | 390.56 | CTD C14M | CTD C14M-160 | 160 | 713.01 | 710.22 |
| CTD C8M | CTD C8M-155 | 155 | 394.7 | 393.1 | CTD C14M | CTD C14M-161 | 161 | 717.47 | 714.68 |
| CTD C8M | CTD C8M-156 | 156 | 397.25 | 395.65 | CTD C14M | CTD C14M-162 | 162 | 721.93 | 719.14 |
| CTD C8M | CTD C8M-157 | 157 | 399.8 | 398.2 | CTD C14M | CTD C14M-163 | 163 | 726.38 | 723.59 |
| CTD C8M | CTD C8M-158 | 158 | 402.34 | 400.74 | CTD C14M | CTD C14M-164 | 164 | 730.84 | 728.05 |
| CTD C8M | CTD C8M-159 | 159 | 404.89 | 403.29 | CTD C14M | CTD C14M-165 | 165 | 735.3 | 732.51 |
| CTD C8M | CTD C8M-160 | 160 | 407.44 | 405.84 | CTD C14M | CTD C14M-166 | 166 | 739.75 | 736.96 |
| CTD C8M | CTD C8M-161 | 161 | 409.98 | 408.38 | CTD C14M | CTD C14M-167 | 167 | 744.21 | 741.42 |
| CTD C8M | CTD C8M-162 | 162 | 412.53 | 410.93 | CTD C14M | CTD C14M-168 | 168 | 748.66 | 745.87 |
| CTD C8M | CTD C8M-163 | 163 | 415.08 | 413.48 | CTD C14M | CTD C14M-169 | 169 | 753.12 | 750.33 |
| CTD C8M | CTD C8M-164 | 164 | 417.62 | 416.02 | CTD C14M | CTD C14M-170 | 170 | 757.58 | 754.79 |
| CTD C8M | CTD C8M-165 | 165 | 420.17 | 418.57 | CTD C14M | CTD C14M-171 | 171 | 762.03 | 759.24 |
| CTD C8M | CTD C8M-166 | 166 | 422.72 | 421.12 | CTD C14M | CTD C14M-172 | 172 | 766.49 | 763.7 |
| CTD C8M | CTD C8M-167 | 167 | 425.26 | 423.66 | CTD C14M | CTD C14M-173 | 173 | 770.95 | 768.16 |
| CTD C8M | CTD C8M-168 | 168 | 427.81 | 426.21 | CTD C14M | CTD C14M-174 | 174 | 775.4 | 772.61 |
| CTD C8M | CTD C8M-169 | 169 | 430.35 | 428.75 | CTD C14M | CTD C14M-175 | 175 | 779.86 | 777.07 |
| CTD C8M | CTD C8M-170 | 170 | 432.9 | 431.3 | CTD C14M | CTD C14M-176 | 176 | 784.32 | 781.53 |
| CTD C8M | CTD C8M-171 | 171 | 435.45 | 433.85 | CTD C14M | CTD C14M-177 | 177 | 788.77 | 785.98 |
| CTD C8M | CTD C8M-172 | 172 | 437.99 | 436.39 | CTD C14M | CTD C14M-178 | 178 | 793.23 | 790.44 |
| CTD C8M | CTD C8M-173 | 173 | 440.54 | 438.94 | CTD C14M | CTD C14M-179 | 179 | 797.68 | 794.89 |
| CTD C8M | CTD C8M-174 | 174 | 443.09 | 441.49 | CTD C14M | CTD C14M-180 | 180 | 802.14 | 799.35 |
| CTD C8M | CTD C8M-175 | 175 | 445.63 | 444.03 | CTD C14M | CTD C14M-181 | 181 | 806.6 | 803.81 |
| CTD C8M | CTD C8M-176 | 176 | 448.18 | 446.58 | CTD C14M | CTD C14M-182 | 182 | 811.05 | 808.26 |
| CTD C8M | CTD C8M-177 | 177 | 450.73 | 449.13 | CTD C14M | CTD C14M-183 | 183 | 815.51 | 812.72 |
| CTD C8M | CTD C8M-178 | 178 | 453.27 | 451.67 | CTD C14M | CTD C14M-184 | 184 | 819.97 | 817.18 |
| CTD C8M | CTD C8M-179 | 179 | 455.82 | 454.22 | CTD C14M | CTD C14M-185 | 185 | 824.42 | 821.63 |
| CTD C8M | CTD C8M-180 | 180 | 458.37 | 456.77 | CTD C14M | CTD C14M-186 | 186 | 828.88 | 826.09 |
| CTD C8M | CTD C8M-181 | 181 | 460.91 | 459.31 | CTD C14M | CTD C14M-187 | 187 | 833.34 | 830.55 |
| CTD C8M | CTD C8M-182 | 182 | 463.46 | 461.86 | CTD C14M | CTD C14M-188 | 188 | 837.79 | 835 |
| CTD C8M | CTD C8M-183 | 183 | 466.01 | 464.41 | CTD C14M | CTD C14M-189 | 189 | 842.25 | 839.46 |
| CTD C8M | CTD C8M-184 | 184 | 468.55 | 466.95 | CTD C14M | CTD C14M-190 | 190 | 846.7 | 843.91 |
| CTD C8M | CTD C8M-185 | 185 | 471.1 | 469.5 | CTD C14M | CTD C14M-191 | 191 | 851.16 | 848.37 |
| CTD C8M | CTD C8M-186 | 186 | 473.65 | 472.05 | CTD C14M | CTD C14M-192 | 192 | 855.62 | 852.83 |
| CTD C8M | CTD C8M-187 | 187 | 476.19 | 474.59 | CTD C14M | CTD C14M-193 | 193 | 860.07 | 857.28 |
| CTD C8M | CTD C8M-188 | 188 | 478.74 | 477.14 | CTD C14M | CTD C14M-194 | 194 | 864.53 | 861.74 |
| CTD C8M | CTD C8M-189 | 189 | 481.28 | 479.68 | CTD C14M | CTD C14M-195 | 195 | 868.99 | 866.2 |
| CTD C8M | CTD C8M-190 | 190 | 483.83 | 482.23 | CTD C14M | CTD C14M-196 | 196 | 873.44 | 870.65 |
| CTD C8M | CTD C8M-191 | 191 | 486.38 | 484.78 | CTD C14M | CTD C14M-197 | 197 | 877.9 | 875.11 |
| CTD C8M | CTD C8M-192 | 192 | 488.92 | 487.32 | CTD C14M | CTD C14M-198 | 198 | 882.36 | 879.57 |
| CTD C14M | CTD C14M-199 | 199 | 886.81 | 884.02 | |||||
| CTD C14M | CTD C14M-200 | 200 | 891.27 | 888.48 | |||||
| CTD C14M | CTD C14M-201 | 201 | 895.72 | 892.93 | |||||
| CTD C14M | CTD C14M-202 | 202 | 900.18 | 897.39 | |||||
| CTD C14M | CTD C14M-203 | 203 | 904.64 | 901.85 |
Wholesale bearings, complete bearing types, and low prices. Please contact us if you have any needs.
sales@supply-bearings.com www.supply-bearings.com
